RYSB-T Series automatic stretch blow molding machine
Categories:
RYSB-T Series
WhatsApp/tel:
Details
RYSB-T series of bottle blowing machine has the advantages of high precision, high stability, energy saving, clean, low noise and so on, as a new generation high performance series of bottle blowing machine.
FEATURES
High yield:Due to the adoption of the heating and molding two tracks run separately, blowing of high-speedoperation,thus the output is improved.
Low energy:Due to the adoption of transfer structure, heating the two preform is close by, makes full use of the heat.
Simple:the patent technology chain drive towards technology and double track one clamp separate transfer transmission structure.structure more simple, reliable.
Air recovery system.
Output will be improved 20~30% per unit time.
Power consumption will be saved 10-30%, air consumption will be saved 10-25%(Power consumption dependson bottle shape).
Choose servo control to ensure high-speed operation and precise locating.
| UNIT | RYSB-T4 | RYSB-T6 | RYSB-T8 | |||||||||
| 90/6 | 140/4 | 68/2 | 90/8 | 118/8 | 180/4 | 230/4-56 | 230/4-80 | 68/16 | 90/12 | |||
| Number of cavity | Cavities | 6 | 4 | 12 | 8 | 8 | 4 | 4 | 4 | 16 | 12 | |
| Heating preform spacing | mm | 50.8 | 76.2 | 50.8 | 50.8 | 63.5 | 101.6 | 76.2 | 101.6 | 50.8 | 50.8 | |
| Heating Carriage unit | mm | 160 | 143 | 200 | 174 | 176 | 91 | 90 | 90 | 217 | 252 | |
| Clamping stroke | mm | 20 | 160 | 100 | 120 | 140 | 210 | 260 | 260 | 100 | 120 | |
| Cavity spacing | mm | 101.6 | 152.4 | 76.2 | 101.6 | 152.4 | 203.2 | 254 | 254 | 76.2 | 101.6 | |
| Carriage unit | pcs | 48 | 32 | 72 | 56 | 56 | 28 | 28 | 28 | 96 | 84 | |
| Max. container volume | ltr | 1.5 | 3.5 | 0.6 | 1.5 | 2.8 | 6 | 12 | 12 | 0.6 | 1.5 | |
| Max, neck diameter | mm | 38 | 38 | 38 | 38 | 38 | 80 | 56 | 80 | 38 | 38 | |
| Max. container diameter | mm | 90 | 140 | 68 | 90 | 118 | 180 | 230 | 230 | 68 | 90 | |
| Max. container height | mm | 320 | 350 | 260 | 320 | 350 | 350 | 420 | 420 | 260 | 320 | |
| THEORETICALOUTPUT | bph | 8000 | 3600 | 16000 | 10000 | 8000 | 2800 | 2600 | 2600 | 20000 | 14000 | |
| Max. heating power | kw | 72 | 72 | 118 | 94 | 143 | 108 | 108 | 108 | 143 | 143 | |
| Operating pressure | kg/cm² | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | |
| Blowing pressure | kg/cm² | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | |
| Max. capacity of air flow | m³/min | 6 | 6.5 | 5.2 | 8 | 8 | 8 | 8 | 8 | 7 | 9 | |
| Machine size | m | 5.4x2x2 | 7.1x2x2 | 6.2x2x2 | 6.5x2.1x2 | 7.4x2.2x2 | 8.1x2.1x2 | 9x2.1x2 | ||||
| Machine weight | t | 5 | 6 | 7 | 8 | |||||||
We have our own equipment and strong production capacity
high-quality channels, ensuring the best prices.
FESTO Solenoid Valves
Delta Servo Drive
Components
Panasonic Photoelectric Sensor
Panasonic PLC Expansion
Servo
Omron Intermediate Relay
Huichuan Servo Drive
Huichuan servo drive
THK Linear Guide Slide
