DW Jar series blow molding machine

PP series of bottle blowing machine is a two steps automatic stretch bottle blowing device.

Categories:

RYSB-DW Series

WhatsApp/tel:

WeChat:

Details

FEATURES

The first fly out seal Patent technology,Make it easier for sealing especially jar sealing.
Airbag locking mold,no rolling out.
Easier operation and higher stability.
Air recovery system (air consumption will be saved 10-25%).

		UNIT	RYSB-D01W						RYSB-D02W	RYSB-D03W						RYSB-D04W
		UNIT	68/4	100/2	140/2	200/1	230/1-6L	230/1-12L	280/1	100/4	118/3	118/4	140/3	230/2-6L	230/2-12L	140/4	180/3	200/3
MOLDING	Number of cavity	Cavities	4	2	2	1	1	1	1	4	3	4	3	2	2	4	3	3
	Clamping stroke	mm	100	120	160	230	260	260	310	120	140	140	160	260	260	160	200	200
	Cavity spacing	mm	76.2	114.3	152.4	228.6	266.7	266.7	304.8	114.3	127	127	152.4	266.7	266.7	152.4	190.5	190.5
	Carriage unit	pcs	88	56	42	30	26	26	26	85	75	82	63	36	36	80	64	64
CONTAINER	Max, container volume	ltr	0.6	2	3.5	6	6	12	20	2	2.5	2.8	3.5	6	12	3.5	5	5
	Max. neck diameter	mm	60	75	120	120	120	120	120	75	100	95	120	120	120	120	120	120
	Max. container diameter	mm	68	100	140	200	230	230	280	100	118	118	140	230	230	140	170	170
	Max, container height	mm	250	350	350	350	350	420	500	350	350	350	350	350	420	350	350	350
THEORETICALT OUTPUT	THEORETICALT OUTPUT	bph	4000	1600	1600	600	600	500	300	3000	2400	3000	2100	1200	1000	3200	2000	2000
ELECTRICAL SYSTEM	Max. heating power	kw	36	36	36	36	36	36	36	45	54	45	62	45	45	54	72	72
AIR SYSTEM	Operating pressure	kg/cm²	8	8	8	8	8	8	8	8	8	8	8	8	8	8	8	8
	Blowing pressure	kg/cm²	30	30	30	30	30	30	30	30	30	30	30	30	30	30	30	30
	Max. capacity of air flow	m³/min	1.8	2	2.5	2	2	2.5	3	4	4	5	6	4	8	5.2	5	5.8
MACHINE	Machine size	m	3x1.8x2			3x2x2			3.2x2.6x2	4.5x1.8x2	4.38x1.8x2	4.9x1.8x2	4.5x1.8x2	4.9x2x2		6x2x2	5.55x2x2	6x2x2
MACHINE	Machine weight	t	1.5			1.8			2.2	5					3.5	5

We have our own equipment and strong production capacity
high-quality channels, ensuring the best prices.

FESTO Solenoid Valves

Delta Servo Drive

Components

Panasonic Photoelectric Sensor

Panasonic PLC Expansion

Servo

Omron Intermediate Relay

Huichuan Servo Drive

Huichuan servo drive

THK Linear Guide Slide
